The semi-automatic core remover machine selects a template based on the different diameters of the fruit, pours the fruit into the storage hopper, and only requires workers to place it in the template hole to achieve the effect of feeding and conveying. After the hole is positioned, the fruit continues to be transported and pushed forward. During the transportation and pushing process, the fruit uses the technology of the machine bed for core punching, and the core falls into the core discharging dustpan and automatically flows out and collects together. The fruit that passes through the core will continue to be transported to the next stage for automatic fruit dropping, so that the shape of the discharged fruit remains completely unchanged. The fruit falls into the dustpan and automatically flows out and collects together, achieving the separation of the fruit and the core.

Technical parameters:

Model: FL-460(customized)

Motor power: 1.5KW

Voltage: 380V 50Hz, 3-phase

Operation mode: semi-automatic

Capacity: 460grain/minute

Material: The main body of machine is 304ss,the conveyor belt and mold bowl are food grade

Size: 3200*1400*1250mm

Weight: 520kgs

 Remark: Customized dual workbench equipment of different sizes according to customer requirements.

Equipment characteristics:

(1) The semi-automatic core remover machine adopts a high degree of automation, equipped with a material bin, which is convenient for workers to pick up materials. The mold conveyor belt is manually placed for feeding, and the automatic feeding device is used for conveying and core cleaning. Simply placing the fruit on the template can achieve the separation effect of core and meat, and it can work continuously without interruption, completely solving the difficulties of low efficiency, labor and time consumption in manual core removal.

(2) The structure of the nuclear removal machine is composed of 304 stainless steel thick walled square tubes and channel steel welded together, which enhances the stability of the equipment during startup and operation. All parts are assembled with bolts and equipped with leakage protection, making the operation and maintenance of the equipment more convenient and efficient.

(3) The raw materials of the equipment are made of high-quality 304 stainless steel, which fully complies with the hygiene standards of food processing equipment. The conveyor belt is wear-resistant, tensile, and tear resistant, with a longer service life.

(4) The operation of the core remover machine is simple and convenient, without the need for long-term supervision. Workers only need to place the fruits. The transmission system adopts advanced design concepts and standardized components, and the core punching principle uses the technology of machine tools to stamp the core, ensuring that each equipment meets the highest design standards with high accuracy. Therefore, the core removal rate effect can reach 100%, and the shape of the fruits remains completely unchanged.
