Application:
Widely applied in fields such as agricultural and sideline product processing, food processing, agriculture, mining, and recycling of renewable resources. Intelligent and automated sorting of materials such as Herbs, spices,seeds,petal, dried fruits,rice, tea, miscellaneous grains, and industrial materials (plastics, glass, minerals, etc.). Create enormous value for customers and society in ensuring food safety, enhancing product added value, and improving production efficiency.
Technical parameter:
Model | Capacity (kg/h) | Color selection accuracy (%) | Voltage (V/Hz) | Host power (kW) | Air source pressure (Map) | Gas source consumption (L/min) | Host weight (kg) | Dimensions (mm) |
FL-32 | 200-500 | >99.90 | 380/50 | 0.5-0.8 | 0.6-0.8 | 0.1-0.3 | 180 | 590*1504*1760 |
FL-64 | 800-1600 | >99.90 | 380/50 | 0.8-1.5 | 0.6-0.8 | 0.3-0.8 | 350 | 880*1504*1760 |
FL-80 | 2000 | >99.90 | 380/50 | 1.8 | 0.6-0.8 | 0.3-0.8 | 400 | 900*1504*1760 |
FL-96 | 3500 | >99.90 | 380/50 | 1.8 | 0.6-0.8 | 0.4-0.9 | 300 | 1550*940*1750 |
FL-128 | 5000 | >99.90 | 380/50 | 2.2 | 0.6-0.8 | 0.5-1.0 | 700 | 1314*1504*1760 |
FL-192 | 8000 | >99.90 | 380/50 | 2.5 | 0.6-0.8 | 0.8-1.5 | 950 | 1650*1504*1760 |
FL-320 | 10000 | >99.90 | 380/50 | 3.7 | 0.6-0.8 | 1.3-2.1 | 1280 | 2322*1504*1760 |
FL-2A | 100 | >99.90 | 380/50 | 1.1 | 0.6-0.8 | 0.1 | 200 | 1188*1475*1550 |
Product superiority:
Using Al technology for Image capture processing,Set up backups,Mode backup transmission available.
Intelligent human-machine interface,Easy to learn and understand,Easy to operate.
Using high-speed sensors,Combining visible light full-color camera technology,Real time dynamic monitoring for materials.
Creating leading intelligent lever flexible return technology to replace traditional pneumatic return function, with no internal leakage or external leakage of airflow; Unique superconducting magnetic application, startup control, and current limiting technology, which saves about 70% of power consumption and about 20% of gas consumption compared to ordinary solenoid valves in the industry.
Free selection and self definition of material color, shape, size, and defect area, determination of removed materials, one click intelligent self-control technology, automatic judgment and accurate matching of the optimal sorting scheme, independent operation according to sorting rules, intelligent recognition, and intelligent sorting.
