The heat source adopts the air energy heat pump compression cold air for hot air, by the internal compressor and the internal fan into the cold air, after the air energy heat pump compression into the dryer, into the dryer, after the hot air and material heat exchange to achieve the purpose of drying.

The material is spread to the feeder by the average material device on the conveyor belt, and the material operates in an "S" shape in the dryer. The wind speed and wind pressure generated by the inlet fan spread the hot air fully and evenly in the dryer. Because the lower pressure is greater than the above pressure, the hot air naturally moves upward through each mesh belt, and in addition, the material movement and roll, make the material fully contact with the hot air, fully heat exchange, and improve the drying efficiency.

Air energy heat pump is the world's latest energy system, is by far the most environmentally friendly and energy-saving drying method.The hot air temperature can be set according to the requirements of the material, and the set temperature can be freely controlled between 40-80℃, so that the material after drying does not change color, do not deteriorate, and retain its nutrients.

The feeding conveyor has a total feeding device, which can adjust the thickness of the material according to different accumulation density, try to increase the amount of materials into the dryer, to ensure the output of drying equipment.

Dryer transmission part is the frequency control motor, can according to the material water different to control in the drying internal operation time, to ensure the drying effect of the premise, the maximum efficiency.

Continuous box dryer, the biggest advantage is in the large output, excellent drying effect, small area and other characteristics, drying effect is mainly through the flow, the maximum profit heat, make the material drying more easy.

Significant price advantage is obvious, Charcoal block, mealworm,dry food, flowers,medicinal materials, food products have a lot of drying equipment can be treated,  Mesh belt type air energy drying machine

is cheaper and more practical, higher than drying box output, price advantage is obvious, more practical, bigger market.

Main components of equipment:

Equipment mainly includes: feeding conveyor, dryer main engine, transmission part, feeding conveyor, power distribution cabinet.

Customized size according to customer's capacity requirements.

Conventional equipment size are 4 layers 12 meters and 7 layers 20 meters.

The capacity of 4 layers is more than 1.2 ton.

The capacity of 7 layers is more than 2.5 ton.
