Application field:
Double screw puffed machine covers agricultural products deep processing breakfast convenient porridge,
Couscous rice, artificial rice, breakfast grain food, leisure puffed food and many kinds of snack food, brushed protein, redrawing starch, pet food, fish feed, animal feed, aquatic feed and other processing fields. Double-screw expansion machine is composed of feeding system, extrusion system, rotary cutting system, heating system, cooling system, transmission system and control system. The machine is suitable for a wide range of raw materials, various production products, frequency conversion speed regulation, high degree of automation, smooth operation, long service life.
Full functional double screw expansion host, the equipment performance is better, the gearbox is strong and durable, the screw using a combination of building blocks, suitable for a wider range of products, the cylinder uses embedded alloy sleeve structure, more wear-resistant and durable.
Technical parameter:(Specific, accurate and detailed data can be communicated and discussed with our company)
Model | Capacity (kg/h) | Main power(kw) | Total power(kw) | Screw diameter（mm) | Screw length(mm) | Machine size(m) |
65 | 100-150 | 22 | 35 | 65 | 1150 | 2.7*0.9*1.8 |
70 | 200-300 | 37 | 45 | 70 | 1250 | 2.5*1.0*1.7 |
75 | 300-500 | 55 | 75 | 75 | 1453 | 3.5*1.5*1.8 |
85 | 600-800 | 75 | 100 | 85 | 1780 | 4.5*1.7*2.4 |
95 | 900-1200 | 95 | 125 | 95 | 1960 | 4.7*2.5*3.7 |
110 | 1000-1500 | 100 | 140 | 110 | ||
120 | 1500-2000 | 110 | 160 | 119 | 2500 | 5.8*2.5*2.0 |
140 | 2500-3000 | 160 | 140 | |||
150 | 4000-5000 | 200 | 150 |
